NCP81074BDR2GON SemiconductorSmall, High Speed Low Side MOSFET Driver with 10A sink/source capability Single Channel 10A Low Side MOSFET Driver with CMOS thresholds in SO8, 2500-REEL
¥
8.58
显示的图像仅供参考,应从产品数据表中获得准确的规格。
NCP81074BDR2GON Semiconductor
制造商:
ON Semiconductor
制造商型号#:
NCP81074BDR2G
百芯编号#:
CM22677076
价格(CNY):
¥
8.58
百芯库存:
1,798
个
库存地点:
可供应量:
1,090
个在库
此为供应商库存,需要与销售确认
产品类别:
FET,驱动器
产品描述:
Small, High Speed Low Side MOSFET Driver with 10A sink/source capability Single Channel 10A Low Side MOSFET Driver with CMOS thresholds in SO8, 2500-REEL
The NCP81074BDR2G is a small, high speed, low side MOSFET driver with 10A sink/source capability in 8 pin SOIC package. This single channel, low side MOSFET driver is capable of providing large peak currents into capacitive loads. It can deliver 7A peak current at the miller plateau region to help reduce miller effect during MOSFETs switching transitions. The device exhibits a split output configuration allowing the user to control the turn on and turn off slew rates. It is typically used in isolated bricks, telecom, data centre equipments and secondary synchronous rectifier, server power, telecommunication, data centre power, switch mode power supply, DC to DC converter and power factor correction applications.
High current drive capability reduce switching losses, VDD based threshold input type
Dual input design allows differential input signal for more control
High current drive capability of ±10A
TTL/CMOS compatible inputs independent of supply voltage
High reverse current capability of 10A peak
4ns typical rise and 4ns typical fall times with 1.8nF load
Fast propagation delay time of 15ns with input falling and 15ns with input rising
