IR2109PBFInfineon600V Half Bridge Driver IC with typical 0.2A source and 0.35A sink currents in 8 Lead PDIP package for IGBTs and MOSFETs. Also available in 8 Lead SOIC, 14 Lead SOIC, and 14 Lead PDIP.
¥
46.75
显示的图像仅供参考,应从产品数据表中获得准确的规格。
IR2109PBFInfineon
制造商:
Infineon
制造商型号#:
IR2109PBF
百芯编号#:
CM34107454
价格(CNY):
¥
46.75
百芯库存:
235
个
库存地点:
可供应量:
186
个在库
此为供应商库存,需要与销售确认
产品类别:
FET,驱动器
产品描述:
600V Half Bridge Driver IC with typical 0.2A source and 0.35A sink currents in 8 Lead PDIP package for IGBTs and MOSFETs. Also available in 8 Lead SOIC, 14 Lead SOIC, and 14 Lead PDIP.
The IR2109PBF is a high voltage high speed power MOSFET and IGBT Half-Bridge Driver with dependent high and low-side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction. The logic input is compatible with standard CMOS or LSTTL output, down to 3.3V logic. The output driver features a high pulse current buffer stage designed for minimum driver cross-conduction. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high-side configuration which operates up to 600V.
Floating channel designed for bootstrap operation
Tolerant to negative transient voltage (dV/dt immune)
