The INA282AIDR is a zero drift series high accuracy, bidirectional current shunt monitor in 8 pin SOIC package. This low or high side, voltage output current shunt monitor can sense across shunts at common mode voltage range from -14V to 80V independent of supply voltage. The low offset of zero drift architecture enables current sensing with maximum drops across the shunt as low as 10mV full scale.
Offset voltage of ±20µV
Common mode rejection ratio (CMRR) of 140dB
Bandwidth of 10KHz
Quiescent current of 600µA
Power supply voltage range from 2.7V to 18V
Input bias current of 25µA
50V/V gain at V+ = 5V
Offset drift of 0.3µV/°C
±1.4% gain error
Operating temperature range from -40°C to 125°C
This integrated circuit can be damaged by ESD. Failure to observe proper handling and installation procedures can cause damage.
